Precision screwdriver rack — two graduated rows for measured driver shafts from 3 to 10 mm.
Twenty pockets in a 180 × 60 mm block. One row runs from 3 to 7.5 mm in 0.5 mm steps for the finest drivers, and the other from 5 to 10 mm for larger ones. Each driver stands by its shaft with the handle up.
The sizes are for the shaft, the part that goes into the pocket, not the handle. Measure your own drivers and change any pocket in Customize; handles that are wide need the pockets spaced further apart.
We check every file opens and matches its stated size. Before printing, compare the printed size with your own measurements.
| Label | Inside size (approx.) | Position |
|---|---|---|
| Row 1 · Pocket 1 | 3.60 mm × 3.60 mm | Left · front |
| Row 1 · Pocket 2 | 4.10 mm × 4.10 mm | Left · front |
| Row 1 · Pocket 3 | 4.60 mm × 4.60 mm | Left · front |
| Row 1 · Pocket 4 | 5.10 mm × 5.10 mm | Left · front |
| Row 1 · Pocket 5 | 5.60 mm × 5.60 mm | Centre · front |
| Row 1 · Pocket 6 | 6.10 mm × 6.10 mm | Centre · front |
| Row 1 · Pocket 7 | 6.60 mm × 6.60 mm | Centre · front |
| Row 1 · Pocket 8 | 7.10 mm × 7.10 mm | Right · front |
| Row 1 · Pocket 9 | 7.60 mm × 7.60 mm | Right · front |
| Row 1 · Pocket 10 | 8.10 mm × 8.10 mm | Right · front |
| Row 2 · Pocket 1 | 5.60 mm × 5.60 mm | Left · back |
| Row 2 · Pocket 2 | 6.10 mm × 6.10 mm | Left · back |
| Row 2 · Pocket 3 | 6.60 mm × 6.60 mm | Left · back |
| Row 2 · Pocket 4 | 7.10 mm × 7.10 mm | Left · back |
| Row 2 · Pocket 5 | 7.60 mm × 7.60 mm | Centre · back |
| Row 2 · Pocket 6 | 8.10 mm × 8.10 mm | Centre · back |
| Row 2 · Pocket 7 | 8.60 mm × 8.60 mm | Centre · back |
| Row 2 · Pocket 8 | 9.10 mm × 9.10 mm | Right · back |
| Row 2 · Pocket 9 | 9.60 mm × 9.60 mm | Right · back |
| Row 2 · Pocket 10 | 10.60 mm × 10.60 mm | Right · back |
How it prints
A solid block with pockets cut straight down: it prints pockets up, with no supports.
